54
CONTROLS
Accessories
IMPORTANT: Follow the procedures for
purging air as instructed by the attachment
manufacturer if specified to do so.
3. Check for leaks.
High Flow Hydraulic System
(If Equipped)
The High Flow function provides additional
flow to the system to operate an attachment
that requires more hydraulic flow (EXAMPLE:
Lawn mower).
This system can be used only for one-way
flow attachments.
¡Auxiliary hydraulic flow rate and rated
pressure:
Flow Rate ... CTL80: 150L/min (39.6 gal/min)
Rated Pressure ..... 20.6 Mpa (2987 psi)
1. Connect the attachment hydraulic lines to
ports (a) and (b).
Refer to page 53 “Connecting the
Hydraullic Circuits”.
Some attachments may have a case
drain, which needs to be connected to the
small port (T).
2. Turn on the High Flow switch (E) (green
light is ON).
3. Press the auxiliary hydraulic switch (A) or
press the heel side (A) of the pedal.
T7B0281
T9B017
To Next Page
