72
OPERATION
Operating Procedures
¡Do not conduct operations with the
cylinders fully extended or retracted. Doing
so applies excessive force on the cylinders
and may damage them.
¡Do not perform scooping or grading
operations with the bucket cylinders fully
extended. The traction force will apply
extremely heavy loads on the bucket
cylinders and this may damage them.
Cautions on Operating
Cautions on Traveling
Traveling over obstacles (rocks, stumps, etc.)
may subject the body to strong shocks and
result in damage. Avoid traveling over
obstacles whenever possible. If you must do
so, keep the bucket near the ground, travel
at low speed, and go over the obstacle at
the center of the crawler.
Cautions on Traveling in 2nd (High) Speed
On uneven ground, travel at low speed and
avoid accelerating, stopping or changing
directions abruptly.
T7D043E
Leave some play
T7D044
T7A013
T7D031
To Next Page
