RS5-34 Telescopic Handler GENERAL
PRINTED IN U.S.A. 101-6 913241
Alt= to hide template information
Alt+ to display template information
Template Name: OML_1_col 907871
Template Date: 1994_04_22
HYDRAULIC SYSTEM
Type...................................................................................................................Open-Center, Fixed-Displacement
Pump ..............................................................................................................................Single-Section Gear-Type
Pump Displacement (revolution) ...............................................................................................2.7 cu. in. (44.3 cc)
Pump Flow (at 2500 RPM) .....................................................................................................29 GPM (110 L/min)
Main Relief Pressure................................................................................................................ 3000 PSI (207 bar)
Steering Relief Pressure .......................................................................................................... 2000 PSI (138 bar)
Main Control Valve .................................................................................................. Parallel, 4-Section Spool Type
Frame Level Control Valve ................................................ Parallel, Single-Section Spool-Type, Joystick Actuated
Auxiliary Control Valve ...................................................... Parallel, Single-Section Spool-Type, Joystick Actuated
Hydraulic Filter
Type.................................................................................................. Remote, 10 Micron, Replaceable Element
Rated Flow....................................................................................................................... 100 GPM (371 L/min)
Rated Pressure......................................................................................................................100 PSI (690 kPa)
By-Pass Pressure (Full Flow)...................................................................................................25 PSI (172 kPa)
Hydraulic Strainer
Location............................................................................................................................ In Tank - Suction Line
Type ................................................................................................................100 Mesh, Replaceable Element
Rated Flow......................................................................................................................... 50 GPM (189 L/min)
By-Pass Pressure ........................................................................................................................3 PSI (21 kPa)
STEERING SYSTEM
Type........................................................................................................ Fixed-Displacement, Hydrostatic System
Displacement/Rev. .................................................................................................................. 17.9 cu. in. (293 cc)
System Pressure...................................................................................................................... 2000 PSI (172 bar)
Steering Cylinders.................................................................................................. Double-Acting, One Each Axle
Steering Mode Valve ..................................................................................... 3-Position, 4-way Solenoid Actuated
Dash Mounted Switch
Steering Modes ............................................................................................................. 2-Wheel, 4-Wheel or Crab
BRAKE SYSTEM
Service Brakes
Type ............................................................................................................................................Wet, Disc-Type
Location ..............................................................................................................................Front and Rear Axle
Actuation.............................................................................................................................. Manual, Foot Pedal
Park Brake
Type ............................................................................................ Spring-Applied, Hydraulic-Release Disc-Type
Location ..............................................................................................................................................Front Axle
Actuation...................................................................................................Electric Switch With Engine Running
Automatic Apply With Engine Shutdown
INSTRUMENTATION
Indicator Lights.............................................................................. Engine Oil Pressure, Alternator, Brake Failure,
Transmission Temperature
Gauges.............................................................................................Coolant Temperature, Fuel Level, Hourmeter
