GENERA
L DIMENSIONS
Based on standard machine equipped with listed tires, 48” (1.2 m) masonry carriage and 48” (1.2 m) pallet forks.
Recommended Tire Type:..................................................... 15.00 x 19.5 12-ply, 405/70 R20 x M27 Traction Type
Overall Length (Less Forks):............................................................................................................ 16’ 0” (4.88 m)
Overall Width: ..................................................................................................................................... 7’10” (2.39 m)
Overall Height: ..................................................................................................................................... 7’ 9” (2.36 m)
Ground Clearance: .............................................................................................................................. 14” (356 mm)
Wheel Base: ............................................................................................................................................9’ 2’ (2.8 m)
Turn Radius (outside): ........................................................................................................................ 12’ 6” (3.8 m)
Machine Weight: ...................................................................................................................... 15,100 lbs. (6855 kg)
