13. Operating Instructions
2-45
• Park on solid, level ground.
• Do not park on a slope. If it is unavoidable to park on a
slope, put solid pieces of wood under the track as
blocks, place the blade on the ground, and dig the
bucket into the ground.
1) Set the right and left travel levers (1) or pedals (2) to the
neutral position to stop the machine.
13-6. Stopping the machine
Do not stop the machine suddenly but provide a
safety margin.
• Do not touch the control levers and pedals acci-
dentally. Otherwise, the implement or the ma-
chine may move unexpectedly, causing serious
bodily injury.
• Whenever leaving the operator's seat, be sure to
place the lock levers securely in the lock position
and remove the starter switch key.
Put the bucket
partially in the
ground
Block
Put the
blade down
000416-00E
015567-00X
(1)
(2)
Lock
(Left side)
(1)
009042-00E
(Left)
(Right)
Neutral
000417-00E
To Next Page
