GEL COMPACT MINI - Programming for End User

22
14.1.10 Set exchange capacity
Display shows:
Exchange capacity is shown in mg/l x m
3
.
Value changes according to the model:
- Compact Mini. Cyclic capacity: 500 mg/l x m
3
corresponding to 50
°f x m
3
.
- Compact Medium. Cyclic capacity: 1000 mg/l x m
3
corresponding to
100 °f x m
3
.
- Compact Maxi. Cyclic capacity: 1400 mg/l x m
3
corresponding to
140 °f x m
3
.
The cursor shows the number to be changed, so press C button to change
the first figure, that is the thousands, and S button to move cursor to the
other figures (hundreds, tens, units).
Press P button to confirm cyclic capacity
.
14.1.11 Set regeneration in presence of iron and/or manganese
Display shows:
In presence of iron and/or manganese, confirm YES with the P button,
otherwise select NO.
14.1.12 Set backwash duration
Display shows:
Such value stands for the duration of the first regeneration cycle
(backwash).
For all Compact models, the duration of the first regeneration cycle is 1
minute.
Press P button to confirm the duration of the first regeneration cycle.
14.1.13 Set brine suction duration
Display shows:
Such value stands for the duration of the second regeneration cycle (brine
suction).
The brine suction duration changes according to the model:
- Compact Mini 12 minutes
- Compact Medium 20 minutes
- Compact Maxi 35 minutes
The cursor shows the number to be changed, so press C button to change
the first figure and S button to move cursor to the other figures.
Press P button to confirm the duration of the second regeneration cycle.
14.1.14 Set final backwash duration
Display shows:
Such value stands for the duration of the third and last regeneration cycle
(final backwash).
The duration of the third regeneration cycle changes according to the
model:
- Compact Mini 2 minutes
- Compact Medium 2 minutes
- Compact Maxi 3 minutes
The cursor shows the number to be changed, so press C button to change
the first figure and S button to move cursor to the other figures.
Press P button to confirm the duration of the third regeneration cycle.
14.1.15 Set salt for regeneration
Display shows:
Such value stands for the amount of salt used in each regeneration.
The kilos of salt used per regeneration change according to the model:
- Compact Mini kg 0,90
- Compact Medium kg 1,70
- Compact Maxi kg 2,50
The cursor shows the number to be changed, so press C button to change
the first figure and S button to move cursor to the other figures.
Press P button to confirm the amount of salt used per regeneration.
14.1.16 Set turbine test
Display shows:
Press P button to confirm NO.
14.1.17 Set Regeneration Tonight
Display shows:
REGENERATION TONIGHT means the possibility to set the appliance to
regenerate the night after programming. Press C button to change NO
into YES and P button to confirm.
14.1.18 Set RO (Reverse Osmosis) System Function
Display shows:
Press P button to confirm NO.
14.2 PROGRAMMING FOR END USER
14.2.1 Start programming
To start, press and hold the P button until “TIME” is displayed. If the
displayed time is correct, press P, otherwise set time of day (see section
14.2.2).
14.2.2 Set time of day
Display shows:
The cursor shows the number to be changed, so press C button to change
the figure and S button to move cursor.
Repeat for all figures until the current hour and minutes are displayed.
When the desired time is displayed, press P button to pass to the next
parameter (14.2.3 Set regeneration time).
Note: Whenever you experience an electrical outage, check your controller
for the correct time. Make any necessary corrections.
14.2.3 Set regeneration time
Display shows:
The cursor shows the number to be changed, so press C button to change
the figure and S button to move cursor.
Repeat for all figures until the regeneration time is displayed.
Press P button to pass to the next parameter (14.2.4 Set number of
people).
Note: It is recommended to set regeneration time when there is no water
consumption. Time recommended for domestic use: 02:00.
Capac. gm 1 5 8 6
72 - 96 hr Regen YES
Backwash 1 0 3. 0
Brine/Rinse 3 0. 0
Backwash 2 0 2. 0
Salt kg. 0 2. 7
Turbine Test NO
Reg. Tonight NO
RO Comp? NO
TIME 08.00
REG. TIME. 0 2 : 0 0
