30 / 32
1434 µPos
14 Order data
Pneumatic connection Code
Air supply / output
via M5 connection thread 1
Air supply / output
via push-in connector,angle, 4 mm 2
Air supply / output
via push-in connector, angle, 6 mm 3
Note: Mounting kit 1434 S01 Z.../4232 S01 Z... depends on the valve type. Please order separately specifying valve type, DN
and control function. Observe mounting kit travel length. A fitting and pneumatic tubing for the valve is included with each
positioner with pneumatic connection (code 2 and 3).
The photo on page 1 shows the GEMÜ 1434 μPos positioner with mounting kit.
Order example
1434 000 Z 1 A 14 3 00 01 010
Type 1434
Field bus (code) 000
Accessory (code) Z
Action (code) 1
Set value input (code) A
Material (code) 14
Pneumatic connection (code) 3
Option (code) 00
Flow rate (code) 01
Travel sensor version (code) 010
Field bus Code
Without (3-wire version) 000
Accessory Code
Accessory Z
Action Code
Single acting, air exhaust 1
Set value input Code
4-20 mA set value input A
0-20 mA set value input B
0-10 V set value input C
Material Code
Aluminium base, PP cover 14
Stainless steel base, PP cover 07
Required parts for remote mounting
GEMÜ 1434...S01 (positioner)
GEMÜ 4232 S01 Z... (travel sensor mounting kit)
GEMÜ 4232 000 Z... 4001 (travel sensor)
GEMÜ 1434 000 Z MP (mounting bracket)
GEMÜ 1219... (connector socket)
Option Code
Without 00
4-20 mA actual value output A0
0-20 mA actual value output B0
0-10 V actual value output C0
Flow rate Code
15 Nl/min 01
Travel sensor version Code
Potentiometer, 10 mm length 010
Potentiometer, 30 mm length 030
Potentiometer external, M 12 connector,
(max. cable length 30 m) S01
Required parts for direct mounting
GEMÜ 1434...010/030 (positioner)
GEMÜ 1434 S01 Z... (travel sensor mounting kit)
GEMÜ 1219... (connector socket)
Required parts for direct mounting above
mounting bracket
GEMÜ 1434...010/030 (positioner)
GEMÜ 1444 000 Z... (mounting kit with travel sensor and
mounting bracket)*
GEMÜ 1219... (connector socket)
* The positioner is mounted using a mounting bracket (GEMÜ
1444 000 Z...) when valves are used that have larger
position changes than the integrated travel sensor on the
positioner can detect. A positioner for remote mounting is
required for this (1434...S01).
