3030 mFlow
12.3 3 SetFunction
Service
1
SetBasics
2
SetFunction
3
SetCalibration
4
Return
6
SETUP
Communication
5
12.3.1 Set the analogue output
Qmin:
Input of the fl ow rate, for which 4 mA should be output.
Qmax:
Input of the fl ow rate, for which 20 mA should be output.
12.3.2 Setting output functions and
switch points
K1 Switch:
Defi nes the output contact type.
NO – make contact or NC – break contact
K1 Fn:
Determines the function of output K1.
OFF No function
(Q min)
Lower than the system flow rate specified
under AlarmMinK1
(Q max)
Exceeds the flow rate that is specified under
AlarmMaxK1
(Q min/max) Lower or higher than the preset flow rate
(T min)
Lower than the temperature value specified
under AlarmMinK1 (only for device version
MT2)
(T max)
Exceeds the temperature value specified
under AlarmMaxK1 (only for device version
MT2)
(T min/max)
Lower or higher than the specified
temperature value (only for device version
MT2)
(TQ1 min)
Lower than the total flow rate value that is
preset under AlarmMinK1
(TQ1 max)
Exceeds the total flow rate value that is
preset under AlarmMinK1
(TQ1 min/max)
Lower or higher than the preset total flow
rate value
(TQ2min)
Lower than the total flow rate value that is
preset under AlarmMinK1
(TQ2 max)
Exceeds the total flow rate value that is
preset under AlarmMinK1
(TQ2 min/max)
Lower or higher than the preset total flow
rate value
Direction Change the flow direction
Warning Warning message
AlarmMinK1:
Sets the lower trigger threshold under which output K1 is
switched.
AlarmMaxK1:
Sets the upper trigger threshold over which output K1 is
switched.
K1 delay:
Determines the delay time of relay K1.
K2 Switch:
Defi nes the output contact type.
NO – make contact or NC – break contact
K2 F:
Determines the function of output K2.
OFF No function
(Q min)
Lower than the system flow rate specified
under AlarmMinK2
(Q max)
Exceeds the flow rate that is specified under
AlarmMaxK2
(Q min/max) Lower or higher than the preset flow rate
(T min)
Lower than the temperature value specified
under AlarmMinK2 (only for device version
MT2)
(T max)
Exceeds the temperature value specified
under AlarmMaxK2 (only for device version
MT2)
(T min/max)
Lower or higher than the specified
temperature value (only for device version
MT2)
(TQ1 min)
Lower than the total flow rate value that is
preset under AlarmMinK2
(TQ1 max)
Exceeds the total flow rate value that is
preset under AlarmMinK2
(TQ1 min/max)
Lower or higher than the preset total flow
rate value
(TQ2min)
Lower than the total flow rate value that is
preset under AlarmMinK2
(TQ2 max)
Exceeds the total flow rate value that is
preset under AlarmMinK2
(TQ2 min/max)
Lower or higher than the preset total flow
rate value
Direction Change the flow direction
Warning Warning message
AlarmMinK2:
Sets the lower trigger threshold under which output K2 is
switched.
AlarmMaxK2:
Sets the upper trigger threshold over which output K2 is
switched.
K2 delay:
Determines the delay time of relay K2.
