3030 mFlow
11 Parameter table
Configuration level Display Function Value range Factory setting
1 Service
Submenu for displaying inputs and outputs
I / O Status
v Current flow velocity ± 12.00 m/s
Q Current flow rate ± 90,000,000 l/h
T Current temperature 0 to 100 °C
Min - T - Max
Minimum and maximum temperature
value
0 to 100 °C
Reset Min T Max Reset the temperature values
DIR Shows the current flow direction Positive/negative
Output K1:K2:K3 Status of the outputs K1, K2, K3
I out Value of current output in mA 0 to 22.0 mA
TQ1 mode Activate totalizer 1 OFF/ON OFF
TQ1 Display the total flow rate of totalizer 1 90,000,000,000 l
TQ2 mode Activate totalizer 2 OFF/ON OFF
TQ2 Display the total flow rate totalizer 2 90,000,000,000 l
Login
Submenu for setting access authorisations
Code Password entry 0...10000 0
Logout Block access OK
New Code: 1 Release the lowest priority 0...10000 0
New Code: 2 Release the medium priority 0...10000 0
New Code: 3 Release the top priority 0...10000 0
Diagnosis
Submenu for displaying diagnostic messages
Error List Displays error messages
hrs Displays operating hours 0 to 9999 h
Warnings Display warnings during operation ON / OFF ON
Clear Error List Delete error list OK
3030 specific
Submenu for displaying the tool identification
Version Device version
S/N Serial number
Configuration level Display Function Value range Factory setting
2 SetBasics
Default Reset to factory settings Yes / No Yes
Display mode
Selection of display indication
under normal working condi-
tions
Q+v
Q+TQ1
Q+TQ2
v+TQ1
v+TQ2
TQ1+TQ2
Q+T (only for version MT2)
v+T (only for version MT2)
Q+v
Unit
Unit of measure of the flow
rate
Decimal point
Determines the number of
digits displayed after the
decimal point
,x / ,xx / ,xxx / Auto Auto
Range Selection of measuring range
Auto
0-4 m/s
0-10 m/s
Auto
Low flow Leak flow volume suppression 0-10 % 1 %
Filter Signal filtering 0.1 to 99.9 s 0.1 s
F.Line Input of mains frequency 50 Hz/60 Hz 50 Hz
D.Refresh Time for display refresh 0.1...1.0 s 0.1 s
DLight Setting the display lighting OnKey / On OnKey
AutoReturn
Time for an automatic return to
the working level
1 to 60 min 5 min
HelpLanguage Text language D / GB D
HelpText Display the help text ON / OFF ON
