3030 mFlow
14 Table for changes to the factory settings
Changed control parameters
Fields marked by X cannot be written into the individual memories but are active for all memories.
Configuration
level
Display Function P1 P2 P3 P4 Factory setting
1 Service New Code: 1 Release the lowest user level X X X 0
New Code: 2 Release the medium user level X X X 0
New Code: 3 Release the top user level X X X 0
Warnings Display warnings ON
Clear Error List Delete error list X X X No Error
Configuration
level
Display Function P1 P2 P3 P4 Factory setting
2 SetBasics Default Reset to factory settings Yes
Display Mode
Selection of display indication under
normal working conditions
Q+v
Unit Unit of measure of the flow rate l/h
DezimalPoint
Determines the number of digits dis-
played after the decimal point
Auto
Range Selection of measuring range Auto
Low Flow Leak flow volume suppression 1,0 %
Filter Signal filtering 0,1 s
F.Line Input of mains frequency X X X 50 Hz
D.Refresh Time for display refresh X X X 0,5 s
DLight Setting the display lighting OnKey
AutoReturn
Time for an automatic return to the wor-
king level
5min
HelpText Display the help text ON
HelpLanguage Text language D
Configuration
level
Display Function P1 P2 P3 P4 Factory setting
3 SetFunction Qmin
Flow rate value, for which 4 mA is
output
0 l/h
Qmax
Flow rate value, for which 20 mA is
output
5000 l/h
K1 Switch Defines the type of output K1 NO
K1 Fn Determines the function of output K1 OFF
AlarmMinK1 Value for the min. alarm K1 0 l/h / 0 °C
AlarmMaxK1 Value for the max. alarm K1 5000 l/h / 100 °C
K2 Switch Defines the type of output K2 NO
K2 Fn Determines the function of output K2 OFF
AlarmMinK2 Value for the min. alarm K2 0 l/h / 0 °C
AlarmMaxK2 Value for the max. alarm K2 5000 l/h / 100 °C
K3 Switch Defines the type of output K3 NO
K3 Fn Determines the function of output K3 OFF
AlarmMinK3 Value for the min. alarm K3 0 l/h / 0 °C
AlarmMaxK3 Value for the max. alarm K3 5000 l/h / 100 °C
PulseOutput Function output of the pulse output Pulse/l
Output Pulse/l Input of the pulses/litres 1 Pulse/l
Output l/Pulse Input of the litres/pulses 1 l/Pulse
Error Time
Determines the delay time between
error recognition and error message
0,2 s
Iout onWar Status of the current output > 20 mA
