Pag.11
3.4
Storage
Store the elevator machine in the original packaging in a dry area protected from the weather or
protect it from dirt and weather until final mounting.
Extreme heat or cold must be avoided!
(storage temperature -10 °C to +50 °C) High
humidity which can lead to condensation must be avoided.
Avoid aggressive conditions (for example salt spray)!
Avoid excessive storage times (we recommend max. one year) and check bearing for correct
function before installing the motor. (Release the brakes and move the rotor by hand. Take care if
the
bearing makes untypical noises)
3.5
Disposal / recycling
Disposal must be carried out professionally and environmentally friendly in accordance with the legal
stipulations. Most of the materials the machine is build of are completely recyclable (i.e. cast iron, steel,
copper wires, …). Check it with your local authorized firms for disposal.
4
Mechanical installation
4.1
General mounting advises
Mounting, electrical connection and commissioning works are only to be performed by trained service
personnel. Adhere to all machinery-related requirements and specifications supplied by the system
manufacturer or machine builder.
Caution!
When working at or in the elevator, the elevator machine and especially the brakes have to be
covered and protected against dust and chips.
Do not install distorted.
Do not apply any force (levering, bending). Above all, do not expose the rotor to any heavy
mechanical shocks.
Before starting installation, the elevator machine must be checked for transport damage, especially
the cables have to be checked.
No welding must be carried out on the elevator machine. The elevator machine must not be used as
a ground point for welding. Magnets and bearings could be destroyed.
The cooling-airflow around the elevator machine must not be obstructed.
We recommend keep at least 130 mm space between the brake and the wall (axial direction) to make
access to the encoder possible.
The brake design with manual hand release must be freely accessible since the levers for
brake release are moved laterally (see chapter “Start-up / manual emergency evacuation)”!
4.2
Fastening the elevator machine
On the bottom side of the machine are 4 threads.
The elevator machine has to be fixed with 4 screws M16 - 8.8 at the mounting bedplate.
Tightening torque M16 - 8.8: 190 Nm.
Screw-in depth at least 1.5 times of screw size (minimum 24 mm, maximum 30 mm).
Fasten the screws crosswise in at least two steps to the required tightening torque.
The
permissible unevenness for the mounting surface is 0.1 mm.
The mounting surface has to be rigid and robust enough to withstand the forces.
For the vibration decoupling of the elevator system, damping elements should be used.
CAUTION!
