GEM GLS Series - Brake; Micro Switch

Pag.30


11.1.3 Brake
Brake type
EVO-01 EVO-02
Brake torque [Nm] 2x250 max 2x500 max
Operating voltage [V DC] 207 207
Rated output power [W] 2x62 2x85
Electrical protection rating IP 54 IP 54
Mechanical protection rating IP 21 IP 21
11.1.3.1 Micro switch
Maximum current [A / V DC] 0.1A
Maximum voltage [V DC] 30VDC
For any further detail about brake see the “INSTALLATION MANUAL FOR EVO BRAKES”.
