11 Main Data
10.1 Technical data (typical applications)
Motor type
GLS20
GLS26 GLS26 GLS34
GLS40 GLS48
Suspension
2:1 2:1 2:1 2:1 2:1 2:1
Typical payload* [kg]
450 630 1000
Rated torque [Nm]
140 200 200 270 355 425
permissible radial load [kg]
3100 3100 3100
Speed [m/s]
1.0 1.0 1.0
Total weight [kg]
115 130 125 140 150 165

Traction sheave
- Diameter [mm]
200 240 200 240 200 240
- Width [mm]
114 114 114 114 114 114
- Rope diameter [mm]
6.5 6.5 6.5
- Standard number of
grooves
5 6 9
- Standard groove distance [mm]
12 12 12
Table shows typical data, other values possible.
Other rope diameters and groove distances are possible.
11.1.1 Protection rating
Component
Protection rating
Motor
IP 21
Absolute encoder
IP 40
Brake (electrical)
IP 54
Brake (mechanical with protection)
IP 21
Complete machine
IP 21
11.1.2 Ambient conditions
The user must ensure that the specified ambient conditions are observed.
Ambient temperature for operation [°C]
-5°C ÷ +40°C
Humidity [%] Maximum 95% / condensation not permitted
Installation height [m above
sea level]
Within 0÷1000m
Above 1000m specify in request of
offer phase.
