17•2 Reference Guide
General Controls
KEYBOARD SENSITIVITY
Determines the response of the keyboard to ve-
locity changes.
Assignable values: Soft, Medium soft, Medium,
Medium hard, Hard.
FOOTSWITCH POLARITY
Footswitch 1, 2, 3
Sets the polarity of the programmable pedals 1,
2, 3. Generalmusic pedals are of the NC type.
Options: NC (Normally Closed), NO (Normally
Open).
Tuning/Scale
MASTER PITCH
Fine tunes the instrument as a whole in fractions
of 1/64 of a semitone.
Assignable values: -63...+63.
KEYBOARD SCALE
Provides a selection of Temperaments (Scales).
Options: Equal, Inverse, Meantone, Werkmeister
III, Arabian 1, Arabian 2, User1 ... User8.
USER PROGRAMMABLE SCALES
You can program your own scale using the key-
board map shown at the bottom of the display.
This graphical representation shows the current
pitch of the notes of an octave. The octave cur-
rently in edit is shown in the title bar directly above
the keyboard (e.g. Octave C-1/B-1). Each note
shows the coarse tune and fine tune status. The
programming tasks allow you to alter the pitch of
one or more notes by modifying the coarse and
fine tuning parameters of the current scale.
Edit General: General controls Edit General: Master pitch & Keyboard Scale
Fine tuning in 64ths of a semitone
Octave (select F5 for «Octave Up»
or F6 for «Octave Down»).
Actual note
Coarse tuning
