Gemalto Cinterion Hardware Interface Description

Cinterion
®
Java Terminals Hardware Interface Description
3.3 Terminal Circuit
35
 EHSxT_BGS5T_HID_v02 2014-05-23
Confidential / Preliminary
Page 22 of 70
3.3 Terminal Circuit
Figure 4 shows a general Java Terminal block diagram that includes all variants. Not every
interface is available for all Terminal products.
Figure 4: Java Terminals circuit block diagram
D‐Sub9‐pin
Level‐
shifter
RS232interface
EMC
RS232driver
Batt+
SIMcard
holder
SIMcardinterface
CCxxx
EMC
Batt+
LED
green
LED
yellow
LED drivers
LED
V180
SMAfemale
Antennainterface
RFout
WesternJack6‐pin
Powersupply
EMC
(on/off)
EMC
power
DC/DC
converter
Vreg
Line
regulator
ON
EMERG_RST
Batt+
Batt+
(Hardware)
Watchdog
LED
active
LED
link
Magnetics
10/100 Ethernet
Phy Controller
KSZ8721
USB
GPIO
connector
12‐pin
EMC
Driver
bidirect.
GPIO
USB‐B
connector
EMC
USB
Electronic
SIM
(opt.)
Micro controller
MII
Quartz
Quartz
AlternativeUSBorEthernetconnector
SMAfemaleSMAfemale
RFin
Rfin
Antennainterfaces
forfutureuse(GNSS,Rxdiversity)
GPIO
connector
8‐pin
EMC
RS485
Driver
Java
module
Supply
VCCref
I²C
GPIO22/WD_RETRIG
Ethernet
RJ45
(forfutureuse)
