Gemalto Cinterion Hardware Interface Description

Cinterion
®
Java Terminals Hardware Interface Description
4.6 Antenna Interface
44
 EHSxT_BGS5T_HID_v02 2014-05-23
Confidential / Preliminary
Page 43 of 70
4.6 Antenna Interface
Table 23 lists RF antenna interface specifications for the Java Terminals. Please note that the
specified conditions may not apply to or be supported by all terminals.
Table 23: RF Antenna interface GSM / UMTS
Parameter Conditions Min. Typical Max. Unit
UMTS/HSPA connectivity Band I, II, V, VI, VIII (not every module variant supports all bands)
Receiver Input Sensitivity @
ARP
UMTS 800/850 Band VI/V -104.7/
-106.7
-110 dBm
UMTS 900 Band VIII -103.7 -110 dBm
UMTS 1900 Band II -104.7 -109 dBm
UMTS 2100 Band I -106.7 -110 dBm
RF Power @ ARP
with
50Ohm Load
Board temperature <85°C
UMTS 800/850 Band VI/V +21 +24 +25 dBm
UMTS 900 Band VIII +21 +24 +25 dBm
UMTS 1900 Band II +21 +24 +25 dBm
UMTS 2100 Band I +21 +24 +25 dBm
GPRS coding schemes Class 12, CS1 to CS4
EGPRS Class 12, MCS1 to MCS9
GSM Class Small MS
Static Receiver input Sensi-
tivity @ ARP
GSM 850 / E-GSM 900 -102 -109 dBm
GSM 1800 / GSM 1900 -102 -108 dBm
RF Power @
ARP
with 50Ohm
Load
GSM GSM 850 / E-GSM 900 33 dBm
GSM 1800 / GSM 1900 30 dBm
