Gemalto Cinterion Hardware Interface Description

Cinterion
®
Java Terminals Hardware Interface Description
4.5 Power Supply Ratings
44
 EHSxT_BGS5T_HID_v02 2014-05-23
Confidential / Preliminary
Page 42 of 70
I
PLUS
Average UMTS supply cur-
rent (average time 3 min.)
IDLE mode @8V 27 79 --- mA
@30V 10.7 12.3 ---
UMTS DATA
(Band I; 23dBm)
@8V 313 411 --- mA
@30V 88.3 113.9 ---
UMTS DATA
Band II; 23dBm
@8V --- 447.6 --- mA
@30V --- 123.8 ---
UMTS DATA
Band V/VI; 23dBm
@8V --- 413.9 --- mA
@30V --- 115 ---
UMTS DATA
Band VIII; 23dBm
@8V 367 410.1 --- mA
@30V 103 114.2 ---
HSPA DATA
(Band I; 23dBm)
@8V 313 411 --- mA
@30V 88.3 113.9 ---
HSPA DATA
Band II; 23dBm
@8V --- 447.6 --- mA
@30V --- 123.8 ---
HSPA DATA
Band V/VI; 23dBm
@8V --- 413.9 --- mA
@30V --- 115 ---
HSPA DATA
Band VIII; 23dBm
@8V 367 410.1 --- mA
@30V 103 114.2 ---
1. Lowest voltage (minimum peak) incl. all ripple and drops >7.6V including voltage drop, ripple and spikes,
measured at western jack (6-pole) pins.
2. Typical values measured with antenna impedance = 50 Ohm (return loss >20dB).
3. BGS5T USB does not support EDGE.
Table 22: Power supply specifications
Para-
meter
Description Conditions Typical Unit
EHS5T
RS485
EHS6T
USB
BGS5T
USB
