Gemini GEM-P801 User Manual

3
Specifications
Current & Voltage Ratings
Alarm Output --------------------------------- Burg: 12 VDC, 2A (max.)
Fire: 12 VDC, 65 mA
Output Current Limiting -------------------- Burg/Fire: 2.25 A
AUX Power: 750 mA
Residential Burglary (4 Hour Standby)
Combined Standby Current: -------------- 500 mA
Bell Output: ----------------------------------- 2 A
(Using Rechargeable 12 VDC 4 AH BATTERY, minimal requirement)
Residential Fire (4 Hour Standby)
Combined Standby Current: -------------- 500 mA
Bell Output: ----------------------------------- 65 mA
(Using Rechargeable 12 VDC 4 AH BATTERY, minimal requirement)
Residential Fire (24 Hour Standby)
Combined Standby Current: -------------- 120 mA
Bell Output: ----------------------------------- 95 mA
(Using Rechargeable 12 VDC 7 AH BATTERY, minimal requirement)
Transformer and Battery
Required Transformer: -------------------- NAPCO TRF12 OR
BASLER 16.5 VAC 20VA
Required Battery: --------------------------- 12V 4 AH or 7 AH Rechargeable
Change Battery every 5 years or as required
Maximum Charging Current: ------------- 165 mA
Maximum Input Current: ------------------- 2.58 A
Loop Characteristics
Loop Voltage: -------------------------------- 5 Volts
Loop Current :-------------------------------- 1.1mA
Loop Resistance:---------------------------- 300
Ω
per zone (max.)
Device Specifications
Max # keypads: ------------------------------ 4, GEM-RP8 current = 65 mA
Max # of receivers: -------------------------- 2, GEM-RECV-XP8
current = 65 mA each
Max # of compatible
2-wire smoke detectors : ------------------ 10
Max Keypad wire length : ---------------- 1000’ total wire length
Miscellaneous
Housing Dimensions : -------------------- 11" x 12
1
/
8
" x 3"
(28 x 30.8 x 7.6) HxWxD
Shipping Weight: --------------------------- GEM-P801 5.5 lbs.
Operating Temperature: ------------------- 0-49ºC (32-120°F)
