上海鲍麦克斯电子科技有限公司 AS系列数控交流伺服系统说明书
9
4: find the needle position signal delay time set by parameter No.
205 [T1] be the tangent, the delay time set by parameter 206 [T2] to
set the time until the majority applied stretch sewing machine.
5: find the next needle position signal after start tangent
action-oriented stop needle stop. Then set the delay time
parameter No. 205 [T1] and then set the parameters for the 206
tangent time [T2]. (Mostly used for general flat car models, and
most of the T1 and T2 set values are set to 0)
Toshiba tangentially oriented needle stop only 203 parameters set
by the angle [TS] Office:
6. Then set the delay time parameter No. 205 [T1] and then set the
parameters for the 206 tangent time [T2].
203 5-359 10
Trimming output start angle TS (down needle position angle as the
reference point) (flat sewing)
204 10-359 120
Trimming output end angle TE (Down needle position angle is the
reference and this value should be bigger than TS) (flat sewing)
205 1-999 10
Trimmer start delay T1 (ms) (interlock)
206 1-999 120
Trimmer end delay T2 (ms) (interlock)
211 5-359 25
Thread release output start angle LS (down needle position angle
as the reference point)
212 10-359 350
Thread release output end angle LE (Down needle position angle is
the reference and this value should be bigger than LS)
213 1-999 1
Thread release output start delay time T1 (ms)
214 1～999 10
Thread release output end delay time T2 (ms) after up needle
position
216 1～999 10
Wiper output delay time (ms)
217 1～9999 70
Wiper duration time (ms)
218 1～999 50
Wiper recovery time (ms)
219 0／1 0
Thread clamp function
0: disable
1: enable
21E 11-359 160
The angle of presser foot solenoid off during thread clamping
220 200～360 360
Stop position after trimming (motor can stop with a reverse angle)
231 0／1 0
Auto test mode:
0: stitches mode
1: time mode
232 0～1000 300
Safe switch filtering time (ms)
