Gendex VisualiX eHD User Manual

Gendex VisualiX
TM
eHD
28
User and Service Manual Doc #4519 986 19041 - April 2005
29
User and Service Manual Doc #4519 986 19041 - April 2005
Technical specications
Available Sensors: eHD Universal Size eHD Large Area
Overall dimensions (mm) 37.5 x 25.5 x 7 40.5 x 33 x 7
Active surface (mm) 31 x 20 34 x 27
Pixel size 19.5 x 19.5 µm 19.5 x 19.5 µm
Image matrix (pixels) 1590 x 1024 1744 x 1384
Max. spatial resolution (lp/mm) 25.6 25.6
Grey scale range 12 bit acquisition
16 bit enhancement
8/16 bit applicat.
12 bit acquisition
16 bit enhancement
8/16 bit applicat.
Maximum grey levels 4096 4096
8 bit image le size (a) 1.590 Kb 2.358 Kb
16 bit image le size (b) 3.180 Kb 4.715 Kb
Saturation dose (*) 250 μGy +/-20% 250 μGy +/-20%
PC Interface USB 1.1 and USB2 compliant
USB Power Supply 5V DC, max 500 mA
IME Dimensions 150 x 85 x 40 cm
System Weight 300 gr. (IME and sensor)
Sensor Cable Length 3 m
USB Cable Length 4.5 m and 2 m supplied
(*) corresponding to 5000 RAD: over 100.000 typical radiographs.
(a)(b) maximum uncompressed le size. An image le can be reduced up to (a)  or (b)  of its original size
depending on the compression method applied without losing signicant information.
