Diagnostics
This section supplies information on some simple tests which the user may perform
in the event of malfunctioning. Refer to the PC manual and the software manual for
information on other types of malfunctions.
The system does not acquire X-ray images:
a) Make sure that X-rays have been emitted.
b) Make sure that the active side of the image sensor is facing the source of X-rays and
that the active area is aligned with the X-ray beam.
c) Make sure that the Intermediate Electronics unit is ready to acquire images (green
led on).
d) If the Intermediate Electronics unit is installed at a distance, check that its cable is
properly connected to the USB port of the Personal Computer.
e) Make sure that only one software program for capturing X-ray images with VisualiX
is running.
f) Check that the sensor has not been disabled in the application program.
g) Check that the software drivers have been installed correctly. Refer to the section
entitled “Status icon”.
Each VisualiX system is supplied with the ImeTest self-diagnostics software. Refer to
Appendix for more information.
