56
13 TECHNICAL PARAMETERS
Specification Parameter
Front Interface Input Ports
Microphone (3.5 mm) x 1, USB (Touch) x 1,
USB (OPS) x 2, HDMI x 1, Display Port x 1,
USB (Android) x 1
Rear side Ports
HDMI x 3, HDMI out x 1, USB (Touch) x 3,
Microphone (3.5 mm) x 1, VGA x 1, VGA Audio x 1,
USB 3.0 x 1, Mini SD Reader x 1
Bottom Ports
AV in x 1, LAN in x 1, LAN out x 1, RS232 x 1,
SPDIF, Earphone x 1
I/O ports Remark
The HDMI 1, Display port and rear side HDMI 4
can support 4K, 30Hz.
The HDMI 2, HDMI 3, HDMI Out ports can
support 4K, 60Hz.
NOTE:
There is an exception that HDMI 1 & 4 ports
can support 4K, 60Hz, when using YUV420
media player device.
Multimedia File Formats Support
Image: JPEG, BMP, PNG
Video: MPEG1, MPEG2, MPEG4, H.264, H.265,
RM, RMVB, MOV, MJPEG, VC1, DivX,
FLV (Support 1080P, 4K HD Decoding)
Audio: MP3, M4A, (AAC)
Speaker Position Forward
Speaker Rated Impedance 8 Ω
Speaker Freq. Response 90 Hz (±20%) – 18 kHz
Speaker Max. Power Output 15 W*2
Transmission Range 5 m
Storage Temperature/Humidity -20°C – 60°C, 20% – 90%
Working Temperature/Humidity 0°C – 40°C, 20% – 80%
Installation Method Wall-mounted / Floor Stand
* We may modify the user manual without prior notice.
* If you discover any unclear presentation, mistake or omission in this manual,
please contact us immediately. We are not liable for any loss or damage if you
fail to contact us.
