Installation Requirement
Bearing
You can choose the portable or a wall-mounting method according to your
needs. The wall mounting can substantially save space.
If you choose portable mounting, use the mounting rack or support. If you want
to use a self-made mounting rack, the bearing capacity of the rack should be
at least four times of the display weight. The bearing capacity of the mounting
support must be four times of the actual weight of the display to ensure
steadiness of the interactive display.
When you choose wall mounted, the bearing capacity of the mounting surface
must be at least four times of the weight of the display. When the mounting
surface is a wall or ceiling of a building, the wall must be built with solid bricks,
concrete or materials of equal intensity. If you need to mount the display on a
loose surface such as an old brick wall, wood plank wall, solid wall, metal or
non-metal structure wall or a wall with a thick decoration layer, take necessary
consolidating measure to ensure that the display is steadily mounted.
Ventilation
Ventilation
requirements
Distance to the surface for installation (mm)
Nominal power
Left and right
sides
Top Bottom Back
Larger than 100 W 100 200 200 100
WARNING
If the product is mounted inside a wall or a cabinet, in addition to the preceding
requirements, the area of ventilation holes at the bottom, top and two sides must
be at least 50% of the sealing surface to ensure proper ventilation.
