Generac Power Systems 13 kW NG

Page 165
DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
1 4 NUT LOCK HEX M8-1.25 NYLON INSERT
2 8 WASHER FLAT M8-5/16
3 1 GASKET, EXHAUST (8KW)
2 GASKET, EXHAUST (10KW)
2 GASKET, EXHAUST
4 1 MANIFOLD, EXHAUST
5 AR SCREW SHC M8-1.25 X 20
6 1 ENGINE ADAPTOR (8KW & 10KW)
7 1 STATOR
8 1 ROTOR
9 1 BEARING
10 2 SCREW HHTT M6-1.0 X 10
11 1 ALTERNATOR AIR IN DUCT
12 1 ALTERNATOR AIR IN BELLOWS
13 1 BEARING CARRIER
14 1 ASSEMBLY BRUSH HOLDER
15 2 SCREW HHTT M5-0.8 X 16
16 4 BOLT, IHHCS M8-1.25
17 1 U-BOLT 5/16” X 1.62” WITH SADDLE
18 1 FLEX PIPE
19 4 SCREW HHTT M8-1.2 X 12
20 4 SCREW TAPTITE M6-1.0 X 12
21 1 MUFFLER
22 1 FLEX COVER
23 1 TAIL PIPE
24 1 FAN, CURVED BLADE
25 1 WASHER FLAT .406 ID X 1.62 OD
26 1 BOLT IHHC
27 2 SCREW HHC 5/16-18 X 1-1/4” G5
28 1 BRACKET, ALTERNATOR MOUNTING
29 AR WASHER LOCK M8-5/16
30 1 GASKET, AIR CLEANER (8KW ONLY)
31 4 SCREW HHC M8-1.25
32 3 5/16 SPECIAL LOCK WASHER
33 1 EARTH STRAP 3/8 X 3/8
34 1 BRACKET ENGINE MOUNTING
35 1 CABLE, #6 30” BLACK BATTERY
36 4 RUBBER MOUNT
37 1 SCREW HHTT M8-1.25 X 16
ITEM QTY. DESCRIPTION
38 4 SCREW PLASTITE 1/4-15 X 3/4” (8KW
ONLY)
39 1 AIR IN SNORKEL (8KW ONLY)
40 2 BAND HOSE CLAMP n35.05 (8KW ONLY)
41 1 AIR FILTER (8KW ONLY)
42 1 AIR BOX (8KW ONLY)
43 4 WASHER FLAT 3/8 (8KW & 10KW)
44 AR WASHER LOCK 3/8
45 4 BOLT HHC 3/8-16 X 1.25” (8KW & 10KW)
46 AR HOSE CLAMP 3/4” ID
47 1 HOSE RES 1/2 LP GAS
48 1 CLAMP HOSE .38-.87
49 6 NUT FLANGE 5/16-18 NYLOK
50 3 CLAMP HOSE #24 B1.06-2.00 (10KW
ONLY)
51 1 HOSE, INTAKE (10KW ONLY)
52 1 CHOKE HOUSING (10KW ONLY)
53 2 SCREW PPPH HI-LO #6/1/2 W/ #5HD
(10KW ONLY)
54 1 BOOT, CHOKE SOLENOID (10KW ONLY)
55 1 COTTER PIN (10KW ONLY)
56 1 SOLENOID, 6 VOLTS DC (10KW ONLY)
57 1 SPRING-CHOKE RETURN (10KW ONLY)
58 1 LINKAGE, CHOKE (10KW ONLY)
59 1 ASSEMBLY, CHOKE SHAFT (10KW ONLY)
60 1 VALVE, CHOKE (10KW ONLY)
61 2 SCREW PFHM M3-0.5 X (10KW ONLY)
62 2 SCREW PPHM #4-40 X 3/8 SEMS (10KW
ONLY)
63 3 SCREW PPPH HI-LO #14-15 X 1/2 (10KW
ONLY)
64 2 BAND CLAMP DIA 36-39MM
65 1 AIR CLEANER (10KW ONLY)
66 2.6 FT TAPE ELEC UL FOAM 1/8 X 1/2
67 1 THROTTLE ROD (8KW ONLY)
68 1 ASSY STEPPER MOTOR (8KW ONLY)
69 1 PLUG, GEAR COVER (13KW – 20KW)
70 1 PLUG, GEAR COVER – SMALL (13KW –
20KW)
71 1 SPRING, ANTI-LASH (8KW ONLY)
