Page 167
DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
1 1 GASKET, DOOR SEAL
2 1 ENCLOSURE FRONT PANEL
3 1 FOAM, FRONT PANEL ENCLOSURE
4 1 EXHAUST BAFFLE (13KW-20KW)
5 AR SCREW HHFC M6-1.0 X 20 (8KW, 10KW)
6 1 PANEL, ENGINE DIVIDER
7 1 BAFFLE, INTAKE
8 AR SCREW TAPTITE M6-1.0X12
9 AR GROMMET OVAL 31.75 X 50.8
10 1 MOUNTING CLIP
11 1 CONTACTOR, STARTER (8KW)
12 1 CABLE, #6 RED BATTERY 38.5”
13 AR WASHER, LOCK M6-1/4”
14 1 NUT HEX 1/4-20 (8KW ONLY)
15 2 SCREW HHC, M6-1.0 X 12 (8KW)
16 1 GROMMET, n38.1 CROSS SLIT
17 1 GASKET, ENGINE DIVIDER
18 17 PANEL CLIP, M6-1.00
19 1 REGULATOR ASSEMBLY
20 1 LUG SLDLSS #2-#8 X 17/64 CU
21 1 LOCK WASHER, SPECIAL 1/4
22 4 PANEL CLIP, 5/16-18
23 4 SCREW, SHC-3/8-16 WITH LOCKING PATCH
24 4 BUSHING
25 1 ENCLOSURE, BASE
26 1 FOAM, FRONT EXHAUST SHIELD
27 1 FRONT EXHAUST SHIELD
28 1 SCROLL, FAN (8KW, 10KW)
29 1 PANEL, EXHAUST DIVIDER
30 1 FOAM, EXHAUST END PANEL
31 2 FOAM, EXHAUST END PANEL SIDES
32 1 ENCLOSURE, EXHAUST SIDE PANEL
33 1 HINGE ASSEMBLY – LEFT SIDE
34 1 FOAM, BACK EXHAUST COMPARTMENT
35 1 ENCLOSURE, BACK PANEL
36 1 RF COVER PLATE, PLASTIC
37 1 BADGE HOLDER - OVAL
38 1 GROMMET, n38.1 CROSS SLIT WITH HOLE
39 3 1.00” THICK FOAM, ENCLOSURE ROOF
40 1 PUSHBUTTON WIRE TIE
41 1 HINGE ASSEMBLY – RIGHT SIDE
42 AR NUT, LOCKING FLANGE M6-1.00
43 2 1/4 TURN LOCKING HATCH
44 2
LATCH PAWL
ITEM QTY. DESCRIPTION
45 1 BRACKET, CONTROL PNL FRONT
46 1 ENCLOSURE END PANEL
47 2 SCREEN
48 2 U-CLIP, M6-1.00
49 2 SCREW HHFC M6-1.0 X 14
50 1 FOAM, ENCLOSURE BACK PANEL
51 11 FT GASKET, EXTRUDED TRIM
52 1 COVER, FRONT TOP EXHAUST
53 1 FOAM, FRONT TOP EXHAUST COVER
54 1 COVER, BACK TOP EXHAUST
55 1 FOAM, BACK TOP EXHAUST COVER
56 1 MOUNTING PAD
57 1 CROSS SUPPORT
58 12 WASHER, SELF LOCKING
59 1 HARNESS GENERATOR TO EXTERNAL CONNECTION
BOX
60 2 WASHER FLAT M5
61 5 WASHER LOCK #10
62 2 SCREW PPHM#10-32 X 1
63 5 NUT HEX #10-32
64 1 POWER BLOCK
65 1 WASHER SHAKEPROOF EXT 1/4 STEEL
66 1 NUT HEX M6-1.0
67 1 EXTERNAL CONNECTION BOX
68 1 LOUVER, SNAP IN
69 1 CONTROL PANEL FASCIA
70 1 WIRE ASSY, CNTRL TO STARTER (8KW ONLY)
71 1 PLUG 6.35 BLACK
72 1 GASKET, EXHAUST DIVIDER
73 AR SCREW SWT 1/4-20 X 5/8
74 1 1/4 SHAKEPROOF WASHER
75 2 THREADED SPACER M6-1.0
76 2 NUT TOP LOCK FLANGE M6-1.0
77 1 SCREW HHC, M6-1.0 X 16
78 4 WASHER FLAT 3/8
79 4 NUT, HEX 3/8-16
80 1 CLAMP STL/VNL (8KW)
81 1 ENCLOSURE ROOF ASSY, GALV.
82 2 BRACKET, EXHAUST (20KW ONLY)
83 AR BRACKET, L
84 4 SCREW HHFC M6-1.0 X 12 (16kW, 17kW ALUM,
20kW)
85 4 NUT HEX FL WHIZ M6-1.0 (16kW, 17kW ALUM,
20kW)
