DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
64 1 WASHER FLAT M8 – 5/16
65 2 KNOB, AIR CLEANER ORG
66 1 COVER, AIRBOX NG/LP
68 1 ELEMENT, AIR CLEANER
69 1 ASSY, MIXER / AIRBOX 990
70 4 SCREW SHLDR(8MM) M6-1.0 X 21
71 4 WASHER,RUBBER 1/4" X 1/8" THICK
72 2 SPARKPLUG
73 2 SCREW TAPTITE M5 – 0.8 X 8
74 1 WRAPPER, LOWER CYLINDER 2 ZINC
75 1 SWITCH, OIL PRESS
76 1 EXTENDED BARBED STR ¼ NPT X 3/8
77 1 OIL FILTER, 90mm
78 1 ASSY, OIL DRAIN HOSE ORG
79 2 SCREW M3 – 0.5 X 6 SEMS
80 1 SWITCH, THERMAL 293F
81 1 BARBED STRAIGHT 1/4NPT X 3/8
82 5 CLAMP, HOSE OETIKER STEPLESS 18.5mm
83 2 HOSE 3/8" 300PSI 6" LG OIL
84 1 COOLER, OIL
85 4 SCREW PLASTITE 1/4-15 X 3/4
86 2 GASKET, MANIFOLD / PORT
87 1 MANIFOLD CYLINDER 2
88 4 SCREW, HHTT M6-1 x 10 LONG
89 1 NUT, HEX LOCK M5-0.8 ZINC
90 4 SCREW SHC M8 – 1.25 X 20 SEMS
91 13 SCREW TAPTITE M6–1X12 CLEAR ZINC
92 1 ASSY,GROUND WIRE CONNECTOR
93 1 WASHER, 25MM I.D.
94 1 NUT, HEX M24
95 4 NUT, GROMMET 1/4 PLUG
96 1 GUARD, FAN
97 1 HOUSING, BLOWER NG COOLER
98 2 SCREW HHFCS M8 – 1.25 X 10 G8.8
99
100 1 PLATE, FAN
101 1 FAN, NYLON
102 1 ASSY, FLYWHEEL
103 1 PLATE, BACKING WITH CUT OUT
104 1 MANIFOLD CYLINDER 1
105 2 SLEEVE, RUBBER
106 1 KEY, WOODRUFF 4 X 19D
107 1 HOSE BREATHER
108 1 WRAPPER, LOWER CYLINDER 1 ZINC
109
1 WRAPPER, UPPER CYLINDER 1 ZINC
110 1 WRAPPER, UPPER CYLINDER 2 ZINC
ITEM QTY. DESCRIPTION
111 1 STARTER MOTOR HEAR REDUCED 1KW
112 2 SCREW HHC M8 – 1.25 X 85 G8.8
113 3 WASHER LOCK M8 – 5/16
114 1 ASSEMBLY, GROUND WIRE
115 2 WASHER LOCK M6 – 1/4
116 4 SCREW TAPTITE M6 – 1.0 X 20 ZINC
117 1 ASSY, IGN COIL W/DIODE, CYLINDER 1
118 1 ASSY, IGN COIL W/DIODE, CYLINDER 2
119 1 ASSY, THROTTLE SHAFT
120 2 THROTTLE VALVE
121 4 SCREW PPHM M3 – 0.5 X 5
122 1 COVER, DUST, MIX/AIRBOX
123 1 SPRING, IDLE ADJUST
124 1 SCREW PPHM M5 – 0.58 X 20
125 2 SCREW HHC M6 – 1.0 X 12
126 1 SCREW BHSC M6-1.0 X 12 SS
127 1 BRACKET, STEPPER MOTOR
129 1 ASSY,CONTROLLER GTH990 HSB
131 1 ASSY, THROTTLE ROD
132 1 BELLOWS, INTAKE
133 1 EXPANSION PLUG
134 3 #10 O-RING
135 1 PLUG, MANIFOLD
136 1 ASSY, AIR BOX BASE
137 1 PIN, FUEL SELECTOR
138 1 PIN, FUEL SEL STOP
139 1 SOLENOID COVER
140 1 LINKAGE, CHOKE
141 4 SCREW PPPH HI-LO #6 X 1/2
142 1 SCREW PHTT M3 – 0.5 X 8
143 1 RETAINER, CHOKE RETURN SPRING
144 1 SPRING, CHOKE RETURN
145 1 WASHER, BELLEVILLE SPRING
146 1 SCREW PPHM M2 – 0.4 X 8
147 1 CHOKE ARM
148 1 SCREW SHOULDER M3 – 0.5 X 6
149 1 VALVE, CHOKE
150 1 SHAFT, CHOKE
151 1 SEAL, GOVERNOR ARM
152 2 SCREW PHM #4 – 40 X 1/4
153 1 BRACKET, SOLENOID
154 1 SOLENOID, 6VDC
155 1 NUT HEX M8 – 1.25 YELLOW ZINC
156 1
SPRING, CHOKE VALVE ADJUST
157 1 SCREW, BHSC M6-1.0 x 12
