Unpacking and Inspection
8 Installation Guidelines for 60 Hz EcoGen™ Generator
Figur
e 2-3. Circuit Breaker Box and Keys
5. Cut the cable tie to remove the keys
.
6. Use
the keys to open the lid of the generator.
NOTE: The enclosed keys provided with this unit are
intended for service personnel use only.
7. There are two locks securing the lid, one on ea
ch
si
de (A in Figure 2-4). To properly open th
e lid,
pr
ess down, on the lid, above the side lock and
unlock the latch.
8. Repeat for the other side. If pressure is not applie
d
f
rom the top, the lid may appear stuck.
NOTE: Always verify that the side locks are unlocked
before attempting to lift the lid.
9. Once the lid is open, remove the front access
panel by lifting it up and out.
NOTE: Always the lift the front access panel up before
pulling away from enclosure (B and C in Figure 2-4). Do
not pull the panel away from the enclosure before lifting
up (D in Figure 2-4)
Figure 2-4. Side Lock Location and Front Panel Removal
000932
