Generac Power Systems D3.4L G16 Extended Tank User Manual

Installation Drawings
42 Installation Guidelines for Protector Diesel Generators
D2.2L G22 Extended Tank (10000018412, page 2 of 2)
888 [35.0]
851 [33.5]
MOUNTING CENTERS
TYP
19 [.7]
TYP
438 [17.2]
291 [11.5]
FUEL TANK
HEIGHT
110 [4.3]
TYP
690 [27.2]
TYP
1216 [47.9]
TYP
1769 [69.6]
TYP
2322 [91.4]
TYP
2424 [95.4]
717 [28.2]
2089 [82.2]
TYP
351 [13.8]
227
[9.0]
101 [4.0]
282 [11.1]
266 [10.5]
TYP
487 [19.2]
620 [24.4]
TYP
660 [26.0]
TYP
169 [6.7]
216 [8.5]
314 [12.3]
1314 [51.7]
TYP
1386 [54.6]
TYP
125 [4.9]
STUB-UP
AREA
125 [4.9]
STUB-UP
AREA
253
[10.0]
62 [2.5]
38
[1.5]
786 [30.9]
2160 [85.0]
51
[2.0]
850 [33.5]
FUEL TANK
TOTAL CAPACITY 233 [61]
USABLE CAPACITY 215 [57]
TITLE
NOTE: STUB-UP AREA FOR HIGH
AND LOW VOLTAGE CONNECTIONS,
CIRCUIT BREAKER, NEUTRAL AND
CUSTOMER CONNECTION OPENING.
CAPACITY: LITER [GALLON]
DIMENSIONS: MM [INCH]
16.7 [0.66]
MOUNTING HOLES
(10 PLACES) SEE
NOTE 9
REMOVABLE
STUB-UP COVER
SEE NOTE 4
REAR VIEW
LEFT SIDE VIEW
OUTER TANK EMERGENCY VENT
(2" NPT FEMALE)
INNER TANK NORMAL VENT
(2" NPT FEMALE)
INNER TANK EMERGENCY VENT
(2" NPT FEMALE)
FUEL SUPPLY
OUTER TANK LEAK DETECTOR
HIGH AND
LOW VOLTAGE
STUB-UP AREA
TOP VIEW
FUEL FILL
(2" NPT FEMALE)
FUEL LEVEL
GAUGE/SENDER
CUSTOMER OPTION
(2" NPT FEMALE)
FUEL RETURN
