Generac Power Systems D3.4L G16 Extended Tank User Manual

Installation Drawings
50 Installation Guidelines for Protector Diesel Generators
D3.4L G16 – 132 Gal Tank (10000043316, page 2 of 2)
18.5 [.7]
TYP
851.1 [33.5]
MOUNTING CENTERS
TYP
SEE NOTE 9
888.1 [35.0]
850.1 [33.5]
632 [24.9]
110 [4.3]
TYP
690 [27.2]
TYP
1216 [47.9]
TYP
1769 [69.6]
TYP
2322 [91.4]
TYP
529.3 [20.8]
FUEL TANK
HEIGHT
246.5 [9.7]
1307.6 [51.5]
1418.4 [55.8]
2088.4 [82.2]
TYP
279.9 [11.0]
263.9 [10.4]
TYP
166.9 [6.6]
657.9 [25.9]
TYP
484.7 [19.1]
714.9 [28.1]
116.6 [4.6]
246.5 [9.7]
376.5 [14.8]
2159.6 [85.0] 253.3 [10.0]
62.4 [2.5]
125 [4.9]
*STUB-UP
AREA
51.1 [2.0]
38 [1.5]
125 [4.9]
*STUB-UP
AREA
786 [30.9]
2423.9 [95.4]
314 [12.4]
FUEL TANK
TOTAL CAPACITY 524 [138.5]
USABLE CAPACITY 500 [132]
TITLE
CAPACITY: LITER [GALLONS]
DIMENSIONS: MM [INCH]
*NOTE: STUB-UP AREA FOR HIGH AND LOW
VOLTAGE CONNECTIONS, CIRCUIT BREAKER,
NEUTRAL AND CUSTOMER CONNECTION OPENING.
THIS TANK IS LISTED TO UL142 AND ULC5601
REAR TANK
COVER PANEL
SEE NOTE 4
16.7 [.66] MOUNTING HOLES
(10 PLACES)
REAR VIEW
LEFT SIDE VIEW
OUTER TANK EMERGENCY VENT
(3" NPT FEMALE)
INNER TANK NORMAL VENT
(3" NPT FEMALE)
INNER TANK EMERGENCY VENT
(3" NPT FEMALE)
FUEL LEVEL
GAUGE/SENDER
OUTER TANK
LEAK DETECTOR
FUEL RETURN
FUEL SUPPLY
FUEL FILL
(3" NPT FEMALE)
CUSTOMER OPTION
(3" NPT FEMALE)
HIGH AND
LOW VOLTAGE
STUB-UP AREA
TOP VIEW
