INSTALLING/USING THE RIP FENCE
1. Set the fence down on the rail either at the left
or right of the saw blade.
Note: For short workpieces that fit between the frame of
the saw and the blade , position the fence at the left
side of the blade. For cutting longer or wider workpieces,
position the fence, on the right side of the saw blade.
2.
Adjust the positioning of the fence on the rail
so that the distance from the inside face of the rip
fence to the blade matches the required
width of cut.
For more precise straight line cuts there is a removable rip fence that can be installed on the rail of the bandsaw
table. Proceed as follows:
TO STOP THE MACHINE
1. Press the red “OFF” button at the front of the frame of the bandsaw to stop the motor.
2. Apply the foot brake to immobilize the blade.
3. Turn your dust collector off.
3.
Turn the knob clockwise to lock the fence in
place.
Make sure to lock the fence in place before
starting to cut against the rip fence.
