PARTS LIST
9
0-270
PART N0. REF. N0. DESCRIPTION SPECIFICATION QTY
90270-01 1 FRAME (FOR MODEL 90-270) 1
9
0270HD-01 1 FRAME (FOR MODEL 90-270HD) 1
90270-02 2 HINGE PIN 4
90270-03 3 UPPER DOOR 1
90270-04 4 LOWER DOOR 1
90270-05 5 SOCKET HEAD SCREW 1/4-20 X 3/8" 2
90270-06 6 DOOR LOCK KNOB 1/4-20 X 3/4" 2
90270-07 7 SOCKET HEAD SCREW 1/4" 2
90270-08 8 NUT 1/4 2
90270-09 9 MOTOR (FOR MODEL 90-270) 3HP 1
9
0270HD-09 9 MOTOR (FOR MODEL 90-270HD) 5HP 1
90270-10 10 KEY 8 X 8 X 45 1
90270-11 11 MOTOR PULLEY (FOR MODEL 90-270) 2-1/2"A1 X 24 X 8 1
90270HD-11 11 MOTOR PULLEY (FOR MODEL 90-270HD) 2-1/2"A1 X 28 1
90270-12 12 MOTOR PULLEY FIXING SCREW 5/16-18 X 1/2" 2
90270-13 13 MOTOR BASE 1
90270-14 14 HEX HEAD BOLT 3/8 X 1-1/2 1
90270-15 15 NUT 1/4 1
90270-16 16 HEX HEAD BOLT 3/8 X 1-1/4 4
90270-17 17 FLAT WASHER 3/8" 4
90270-19 19 NUT 3/8" 4
90270-19-1 19-1 LOCK WASHER 3/8" 4
90270-20 20 HEX HEAD BOLT 3/8" X 4" 1
90270-21 21 NUT 3/8" 1
90270-22 22 MOTOR BASE SUPPORT BRACKET 1
90270-23 23 V-BELT (FOR MODEL 90-270) A36 1
90270HD-23 23 V-BELT (FOR MODEL 90-270HD) A38 2
90270-24 24 DUST CHUTE 1
90270-25 25 WOODEN DUST BOARD 1
90270-26 26 HEX HEAD BOLT 5/16"-18 X 3/4" 2
90270-27 27 WASHER 5/16" 2
90270-28 28 NUT 5/16" 2
90270-29 29 PHILLIPS HEAD SCREW 3/16 X 3/8" 2
90270-30 30 DUST PORT 1
90270-31 31 PHILLIPS HEAD SCREW 3/16 X 3/8" 4
90270-32 32 BLADE TENSION INDICATOR 1
90270-33 33 CAP SCREW 3/16 X 1/2 2
90270-34 34 WIRE BRACKET 5 X 50 X 13 1
90270-35 35 PHILLIPS HEAD SCREW 3/16 X 3/8 1
90270-36 36 HEX HEAD BOLT 3/8"-16 X 2" 1
90270-37 37 NUT 3/8"-16 1
90270-38 38 SWITCH BOX (FOR MODEL 90-270) 1
90270HD-38 38 SWITCH BOX (FOR MODEL 90-270HD) 1
90270-39 39 ON SWITCH 30MM 1
90270-40 40 OFF SWITCH 30MM 1
90270-41 41 POWER CONTROL PANEL 2 X 160 X 160 1
90270-42 42 PHILLIPS HEAD SCREW 3/16 X 3/8 4
90270-43 43 CONNECTION PLATE 9 X 38 X 520MM 1
90270-44 44 BRAKE SHOE 1
90270-45 45 HEX HEAD BOLT 3/8"-16 X 1" 1
90270-46 46 HEX HEAD BOLT 1/4"-20 X 1/2" 1
90270-47 47 FOOT BRAKE PEDAL 1
90270-48 48 LOCK WASHER 3/8" 1
90270-49 49 NUT 3/8"-16 1
90270-50 50 SPRING 2.0 X 15 X 120L 1
90270-51 51 NUT 3/8"-16 1
90270-52 52 HEX HEAD BOLT 3/8"-16 X 3/4" 1
90270-53 53 PLASTIC PLATE 1
90270-53-1 53-1 PHILLIPS HEAD SCREW 3/16" X 1/4" 4
FRAME ASSEMBLY
28
