PART NO. REF. N0. DESCRIPTION SPECIFICATIONS QTY
40080-01 32240032A FENCE BODY 910MM 1
40080-02 60100001A LOCK HANDLE 5/16” 2
40080-03 T3224002 SCALE 910MM 1
40080-04 32240052A T-BOLT 6
40080-05 9145162302 FLAT WASHER M8 2
40080-06 939M08000B LOCK KNOB M8 8
40080-07 32240034 LOCK NUT M8 2
40080-08 32240035A H SPACER 401MM 2
40080-09 32240036 FENCE FACES 451MM 2
40080-10 32240037 SAFETY GUARD 1
40080-11 32240038 FENCE SPACER 2
40080-12 32240039 SIDE BRACKET BASE 320MM 2
40080-13 32240040 SIDE BRACKET 375MM 2
40080-14 32240041 RULE PLATE 300MM 2
40080-15 T3224003 SCALE 300MM 2
40080-16 935014000 SQUARE NUT 1/4” 8
40080-17 9140141602 FLAT WASHER M6 14
40080-18 901M06012 CAP SCREW M6 X 12 8
40080-19 HEX BOLT
X 6
40080-20 940M06012 LOCK KNOB M6 X 12 2
40080-32
32240013A DUST PORT 1
40080-33 PHILLIPS HEAD SCREW 2
40080-34 32240033A T-BOLT 2
40080-35 32240060 FLUOROWAY PAD 1
PARTS LIST – #40-080
Router Fence
(#40-080)
