General Excalibur 40-200C

DELUXE ROUTER TABLE KIT (Floor model)
MODEL #40-200C
IDENTIFICATION OF MAIN PARTS AND COMPONENTS
A- ON/OFF SWITCH WITH REMOVABLE SAFETY KEY
B- TABLE*
C-
FENCE RAIL WITH SLIDING SCALE
D- OUTFEED FENCE FACE
E- FENCE LOCKING HANDLE
F- ROUTER LIFT CRANK HANDLE
G- DUST SHIELD LOCK KNOB
H- DUST SHIELD
I- FENCE BODY
J- INSERT RING WRENCH
K- INFEED FENCE FACE
L- 3/4” X 3/4” MITER T-SLOT (FOR MITER GAUGE)
M- 3/8” MITER T-SLOT (FOR SELF MADE JIGS)
N- INSERT RING WRENCH STORAGE
7
T
O- DUST ENCLOSURE BOX ACCESS DOOR
P- AIR VENT
Q- ROUTER LIFT HANDLE HOLDER
R- STAND
S- STAND CASTER PEDAL
T- LEVELING FEET
U- CASTERS
V- 2 1⁄4” BRANCH INLET
W- DUST HOSE
X- 4” DUST PORT
Y- DOVETAIL SLOT
L
* Model 40-200C Cast-iron table shown.
V
X
W
Y
REAR VIEW
DOVETAIL SLOT
L
* Model 40-200C Cast-iron table shown.
