Carefully unpack and remove the components of the following 5 boxes - that make up a complete Excalibur Router
Table - and check for damaged or missing items as per the list of contents below.
NOTE: Please report any damaged or missing items to your General International distributor immediately.
UNPACKING
LIST OF CONTENTS QTY
40-080 ROUTER FENCE (40-200)
a- DUST SHIELD ...................................................... 1
b-
2 1⁄4” dust collection outlet. .......................... 1
c-
FENCE LOCKING HANDLE ............................... 2
d-
FENCE BODY .................................................... 1
e-
FENCE FACE ......................................................... 2
f-
FENCE SIDE RAIL W/SCALE ................................ 2
g-
FENCE MOUNTING BRACKET .......................... 2
h-
SPACER BARS (FOR JOINTING WORK) ........... 2
i-
LOCK KNOB ..................................................... 8
j-
T-BOLT (LONG) ................................................. 6
k-
CAP SCREW ...................................................... 6
l-
PLASTIC SPACER ............................................... 2
m- FLAT WASHER (SMALL)
................................... 14
n-
T-BOLT (SHORT) ................................................. 2
o-
PHILLIPS HEAD SCREW ..................................... 2
p-
HEX NUT (LARGE) ............................................. 2
q- FLAT WASHER (LARGE) ..................................... 2
r- SQUARE NUT ..................................................... 8
s- HEX HEAD BOLT ................................................ 6
8
40-080 ROUTER FENCE (40-200)
a
b
c
e
g
f
h
d
j
n
p
q
s
r
k
l
o
m
i
