General Excalibur 40-200C User Manual

Carefully unpack and remove the components of the following 5 boxes - that make up a complete Excalibur Router
Table - and check for damaged or missing items as per the list of contents below.
NOTE: Please report any damaged or missing items to your General International distributor immediately.
UNPACKING (CNT’D)
40-125 ROUTER LIFT
LIST OF CONTENTS QTY
40-125 ROUTER LIFT
a- ROUTER LIFT ...................................................... 1
b-
ROUTER LIFT CRANK HANDLE .......................... 1
c-
INSERT RING WRENCH ..................................... 1
d- STARTER PIN
....................................................... 1
e-
HEX SOCKET HEAD BOLT .................................... 2
f-
2.5 MM ALLEN KEY ........................................... 1
g-
3 MM ALLEN KEY .............................................. 1
h-
4 MM ALLEN KEY .............................................. 1
i-
6 MM ALLEN KEY .............................................. 1
LIST OF CONTENTS QTY
40-130 DUST COLLECTION KIT
a- RIGHT SIDE PANEL ............................................ 1
b-
BOTTOM PANEL ................................................ 1
c-
REAR PANEL ...................................................... 1
d- LEFT SIDE PANEL
................................................ 1
e-
FRONT PANEL ....................................................... 1
f-
DUST HOSE ........................................................... 1
g-
DUST PORT ........................................................ 1
h-
HOSE CLAMP .................................................... 2
i-
HEX HEAD BOLT ................................................ 6
j-
LOCK WASHER ................................................. 6
k-
FLAT WASHER .................................................... 6
l-
PHILLIPS HEAD SCREW (SHORT) ....................
m- PHILLIPS HEAD SCREW (LONG)
.......................
a
b
c
d
e
f g
h
i
40-130 DUST COLLECTION KIT
a
b
c
d
e
f
g
h
i
k
j
l
m
9
3
6
........................................................
8
2
