Genicom LA36N - Step 3: Assembling the Printer

1-5
Step 3
Assembling the Printer
This section explains how to mount the platen knob and how to install the cut sheet stand
and ribbon cartridge.
Mounting the Platen Knob
The platen knob allows you to manually feed the paper.
To mount the platen knob:
1. Insert the platen knob 1 on the platen axle 2 on the right side of the printer.
2. Push the platen knob 1 until it stops against the axle 2.
Mounting the Platen Knob
2
1
