Section 2 • Specifications
REV B
September 2016
2 - 2 GRC Part No. 227123
SPECIFICATIONS
Performance Specifications
Drive speed, maximum
Platform stowed, fast 2.5 mph
40 ft / 10.9 sec
4 km/h
12.2 m / 10.9 sec
Platform stowed, slow 1.1 mph
40 ft / 24.8 sec
1.8 km/h
12.2 m / 24.8 sec
Platform raised 0.5 mph
40 ft / 55 sec
0.8 km/h
12.2 m / 55 sec
Braking distance, maximum
High range on paved surface 19 in ± 6 in
48 cm ± 15 cm
Gradeability 30%
Airborne noise emissions
Sound pressure level at ground workstation < 70 dBA
Sound pressure level at platform workstation < 70 dBA
Maximum slope rating,
Function speed, maximum, from platform controls
(with 1 person in platform)
Platform up (fast mode) 10 to 14 seconds
Platform up (slow mode) 34 to 36 seconds
Platform down 14 to 18 seconds
Rated work load at full height, maximum
Platform 500 lbs
227 kg
Hydraulic Specifications
Hydraulic Oil Specifications
Hydraulic oil type Chevron Rykon MV equivalent
Viscosity grade Multi-viscosity
Viscosity index 200
Cleanliness level, minimum ISO 15/13
Water content, maximum 200 ppm
Chevron Rykon MV oil is fully compatible and
mixable with Shell Donax TG (Dexron III) oils.
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation, corrosion inhibition, seal conditioning, and
foam and aeration suppression properties.
Optional fluids
Biodegradable Petro Canada Environ MV 46
Statoil Hydra Way Bio Pa 32
BP Biohyd SE-S
Fire resistant UCON Hydrolube HP-5046
Quintolubric 822
Mineral based Shell Tellus T32
Shell Tellus T46
Chevron Aviation A
Continued use of Chevron
Aviation A hydraulic fluid when
ambient temperatures are
consistently above 32°F / 0°C may
result in component damage.
Note: Use Chevron Aviation A hydraulic fluid
when ambient temperatures are consistently
below 0°F / -17°C.
Note: Use Shell Tellus T46 hydraulic oil when oil
temperatures consistently exceed 205°F / 96°C.
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult the Genie
Service Department before use.
