Section 4 • Repair Procedures
REV A
September 2016
Part No. 227123 GRC 4 - 5
1-4
Platform Emergency Stop Button
How to Remove the Platform
Controls Emergency Stop Button
1 Push in the red Emergency Stop button to the
off position at both the ground and platform
controls.
2 Disconnect the platform controls from the
control cable at the platform.
3 Remove the fasteners securing the platform
control box to the platform control bracket.
4 Remove the fasteners securing the bottom
cover to the platform control box. Open the
control box.
5 Disconnect the white wires from the Emergency
Stop base.
Electrocution/burn hazard. Contact
with electrically charged circuits
could result in death or serious
injury. Remove all rings, watches
and other jewelry.
Component damage hazard.
Electrostatic discharge (ESD) can
damage printed circuit board
components. Maintain firm contact
with a metal part of the machine
that is grounded at all times when
handling printed circuit boards OR
use a grounded wrist strap.
6 Carefully remove the Emergency Stop base
from the Emergency Stop button.
7 Carefully remove the retaining ring from the
Emergency Stop button.
8 Carefully remove the Emergency Stop button
from the platform control box.
PLATFORM CONTROLS
