Section 4 • Repair Procedures
REV A
September 2016
Part No. 227123 GRC 4 - 13
How to Remove the
Hydraulic Pump
Note: When removing a hose assembly or fitting,
the O-ring on the fitting and/or hose end must be
replaced and then torqued to specification during
installation. Refer to Section Two,
Hydraulic Hose
and Fitting Torque Specifications.
1 Tag, disconnect and plug the hydraulic supply
hard line at the pump. Cap the fitting on the
pump.
2 Tag, disconnect and plug the high pressure
hose at the pump. Cap the fitting on the pump.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to squirt
or spray.
3 Remove the pump mounting bolts. Carefully
remove the pump.
Tip-over hazard. After replacing
the hydraulic pump, it is critical to
return the function speed settings
to original factory specifications.
Failure to restore the machine to
original factory specifications
could cause the machine to tip
over, resulting in death or serious
injury.
HYDRAULIC PUMP
