ADVANCED PROGRAMMING F + +
Display Function Default
AS
ASSISTANCE REQUEST (combined with next fun-
ction):
If activated, at the end of countdown (settable
with the next function i.e. “Cycle programming”)
it effects 2 sec. of pre-flashing (in addition to the
value already set with the PF function) at every
Open pulse (job request). Can be useful for setting
scheduled maintenance jobs.
Y
= Active
no
= Disabled
no
nc
CYCLE PROGRAMMING:
For setting countdown of system operation cycles.
Settable (in thousands) from
00
to
99
thousand
cycles.
The displayed value is updated as cycles pro-
ceed.
This function can be used to check use of the
board or to exploit the “Assistance request”.
00
St
GATE STATUS:
Exit from programming and return to gate status
viewing (see Chpt 5.1.).
To reset the programming default settings, check if the edge input
is opened (SAFE LED OFF), and simultaneously press keys +, - and F,
holding them down for 5 seconds.
Modification of programming parameters comes into effect imme-
diately, whereas definitive memory storage occurs only when you
exit programming and return to gate status viewing. If the equipment
is powered down before return to status viewing, all modifications
will be lost.
6. START-UP
6.1. INPUTS CHECK
The table below shows the status of the LEDs in relation to to the status of
the inputs.
Note the following: Led lighted = closed contact
Led off = open contact
Check the status of the LEDs as per Table.
The status of the LEDs while the gate is closed at rest are shown in
bold.
dl = -3
= Right-hand opening movement
LEDS LIGHTED OFF
FCA Limit-switch free Limit-switch engaged
FCC Limit-switch free Limit-switch engaged
OPEN B Command activated Command inactive
OPEN A Command activated Command inactive
FSW OP Safety devices disengaged Safety devices engaged
FSW CL Safety devices disengaged Safety devices engaged
STOP Command inactive Command activated
EDGE Safety devices disengaged Safety devices engaged
dl = 3-
= Left-hand opening movement
LEDS LIGHTED OFF
FCA Limit-switch free Limit-switch engaged
FCC Limit-switch free Limit-switch engaged
OPEN B Command activated Command inactive
OPEN A Command activated Command inactive
FSW OP Safety devices disengaged Safety devices engaged
FSW CL Safety devices disengaged Safety devices engaged
STOP Command inactive Command activated
EDGE Safety devices disengaged Safety devices engaged
7. AUTOMATED SYSTEM TEST
When you have finished programming, check if the system is operating
correctly.
Most important of all, check if the force is adequately adjusted and if the
safety devices are operating correctly.
