16
ENGLISH
ADVANCED PROGRAMMING F + +
Display Function Default
b0
MAXIMUM TORQUE AT INITIAL THRUST:
The motor operate at maximum torque (ignoring
the torque setting) at start of movement. Useful
for heavy leaves.
Y
= Active
no
= Disabled
Y
br
FINAL BRAKING:
When the gate engages the opening or closing
limit-switch, a braking stroke can be selected
to ensure the leaf is stopped immediately. If
decelerations are selected, braking starts when
they finish.
At
00
value, braking is disabled.
Time can be adjusted from
01
to
20
sec. in 0.1-
second steps.
E.g. if the display indicates
10
, braking time is 1
second.
00
= Braking disabled
from
01
to
20
= Timed braking
05
FS
FAIL SAFE:
If this function is activated, it enables a function
test of the photocells before any gate movement.
If the test fails (photocells not serviceable signalled
by value
05
on the display), the gate does not
start moving.
Y
= Active
no
= Disabled
no
PF
PRE-FLASHING (5 s):
Activates the flashing lamp for 5 seconds before
start of movement.
no
= Disabled
oP
= Only before opening
CL
= Only before closing
OC
= Before every movement
no
SP
INDICATOR-LIGHT:
If
00
is selected, the output functions as a standard
indicator-light (lighted at opening and pause,
flashing at closing, and off when gate closed).
Courtesy light: Different figures correspond to
timed activation of the output, which can be used
(by a relay) to power a courtesy lamp. Time can
be adjusted from
0
to
59
sec. in 1-second steps,
and from
1.0
to
4.1
min. in 10-second steps.
Electric lock command and ‘traffic lights’ fun-
ctions:
If you press key
- from the
00
setting, the
command for the
E1
closing electric lock is
activated;
If you press
- again, the command for the
E2
closing and opening electric lock is set;
if you press the
- key again, you can set the ‘traffic
lights’ functions
E3
and
E4
.
00
= Standard indicator-light
from
01
to
4.1
= Timed output.
E1
= electric lock command before opening
movement
E2
= electric lock command before opening and
closing movements
E3
= ‘traffic lights’ function: the output is active
in “open” and “open on pause” status and is
disabled 3 seconds before the closing manoe-
uvre starts.
there is 3 seconds of pre-flashing before
the closing manoeuvre.
E4
= ‘traffic lights’ function: the output is active
only in “closed” status.
Do not exceed the output’s maximum load
(24Vdc-3W). If necessary, use a relay
and a power supply source outside the
equipment.
00
Ph
CLOSING PHOTOCELLS LOGIC:
Select the tripping mode of the closing photo-
cells.
They operate for the closing movement only: they
stop movement and reverse it when they are
released, or they reverse it immediately.
Y
= Reverse on release
no
= Reverse immediately when opening
no
ADVANCED PROGRAMMING F + +
Display Function Default
oP
OPENING PHOTOCELLS LOGIC:
Select the tripping mode of the opening pho-
tocells.
They operate for the opening movement only:
they stop the movement and restart it when they
are released, or they reverse it immediately.
Y
= Reverse immediately when closing
no
= Restart movement on release
no
EC
ENCODER:
If the encoder is used, you may select its pre-
sence.
If the encoder is present and enabled, “decele-
rations” and “partial opening” are controlled by
the encoder (see relevant paragraphs).
The encoder operates as an anti-crushing device:
If the gate strikes an obstacle during opening or
closing, the encoder immediately reverses gate
leaf movement for 2 seconds. If the encoder ope-
rates again during the 2-seconds reversing time,
it stops movement (STOP) without commanding
any reversing. If no sensor is supplied, the para-
meter must be set on
00
. If there is the encoder,
adjust the sensitivity of the anti-crushing system,
by varying the parameter between
01
(maximum
sensitivity) and
99
(minimum sensitivity).
From
01
to
99
= Encoder active and sensitivity
adjustment
00
= Encoder disabled
00
rP
Pre-limit switch DECELERATION:
You can select gate deceleration before the
opening and closing limit-switches have been
tripped.
Time can be adjusted from
00
to
99
.
If an encoder is used, the adjustment is not deter-
mined by time but by motor revs, thus obtaining
greater deceleration precision.
00
= Deceleration disabled
from
01
to
99
= Deceleration enabled
00
rA
Post-limit switch DECELERATIONS:
You can select gate deceleration after the
opening and closing limit-switches have been
tripped.
Time can be adjusted from
00
to
20
sec. in 0.04-
second steps.
If an encoder (optional) is used, the adjustment
is not determined by time but by motor revs, thus
obtaining greater deceleration precision.
00
= Deceleration disabled
from
01
to
20
= Deceleration enabled
05
PO
PARTIAL OPENING:
You can adjust the width of leaf partial opening.
Time can be adjusted from
01
to
20
sec. in 0.1-
second steps.
If an encoder (optional) is used, the adjustment
is not determined by time but by motor revs, thus
obtaining greater precision of partial opening.
E.g. for a gate with a sliding speed of 10 m /min,
value
10
corresponds to about 1.7 metres of
opening.
E.g. for a gate with a sliding speed of 12 m /min,
value
10
corresponds to about 2 metres of ope-
ning.
05
t
WORK TIME:
We advise you to set a value of 5 to 10 seconds
over the time taken by the gate to travel from the
closing limit-switch to the opening limit-switch and
vice versa. This will protect the motor against any
overheating if a limit-switch fails.
Adjustable from
0
to
59
sec. sec. in one-second
steps.
Subsequently, viewing changes to minutes and
tens of seconds (separated by a point) and time
is adjusted in 10 second steps, up to a maximum
value of
4.1
minutes.
E.g. if the display shows
2.5
, work time is 2 min.
and 50 sec.
the set value does not exactly match the
motor’s maximum operating time, be-
cause the latter is modified according to
the performed deceleration spaces.
4.1
