Zenith15/25 GNSS Series - 4 -
Installation Guide © 2017 GeoMax AG, Widnau, Switzerland
2 GENERAL PREPARATION
2.1 COPY ZENITH15/25 FIRMWARE ON MICROSD CARD
Visit GeoMax Downloads to check for the current versions of both System and GNSS
firmware’s. Download the files and store them on the provided MicroSD card in the
SYSTEM folder
2.2 BATTERY CHARGING
Before using the receiver, the included ZBA201 batteries should be charged. Insert a
battery into the ZCH201 charger and plug the adapter into an AC supply. Do not
disconnect from power until the green FULL indicator flashes, indicating that the battery is
fully charged.
The PS336 handheld is supplied in a cardboard box which includes the handheld device,
battery, charging adapter and EU power cable. A suitable AC power cable may need to be
sourced locally to suit country specific plugs. All AC voltages are supported by the adapter.
Insert the supplied battery into the handheld’s battery compartment. Charge the internal
battery with the supplied adapter as shown below. While charging, the circled indicator on the
front of the PS336 glows amber. Do not disconnect from power until the indicator glows
green, indicating that the battery is fully charged.
