Zeta125/ Zeta125s | 60Auto Target
EN
Switching
between narrow
mode and wide
mode
Detector mode With the detector mode you can use the auto target like a typical detector.
To enter the detector mode:
With the auto target powered down, press and hold the ON/OFF key and
the left arrow key or right arrow key .
Step Description
1.
Press the ON/OFF key to power down the auto target.
2.
With the auto target powered down, press and hold the auto align-
ment key and at the same time turn on the auto target.
3.
Release both, the ON/Off key and the auto alignment key at the
same time.
4. Once the auto target is on:
If the two outside red LEDs are lit solid, the auto target is in wide mode.
If the two outside red LEDs are not lit, the auto target is in narrow
mode.
The auto target starts with the mode that was activated last.
GeoMax_Zeta125_Zeta125s_UM_v1.0.0_en.fm Page 60 Friday, November 28, 2014 9:23 AM
