GeoMax Zone80 DG User Manual

6 Zone80 DG Menu
6.1 Access and Navigation
The Zone80 DG has several menu options that allow you to optimise the performance of the
Zone80 DG for an individual application.
To access the menu of the Zone80 DG, press the Left and Right arrow buttons simultaneously
while the main screen is displayed.
Navigation within the menu:
007606_001
In the bottom right-hand corner of the menu screen, there are
displayed user direction buttons to indicate the navigation within
the Zone80 DG menu.
Press the Up and Down arrow buttons to move the cursor and highlight an icon or an option.
007607_001
A highlighted icon is surrounded by a box.
18299_001
A highlighted option is shaded in black.
Press the Grade button to select a highlighted icon or to enable/disable a highlighted option.
•
If you select an icon, a screen with the options for the selected icon is displayed.
•
If you select the menu icon (MENU 1, MENU 2, MENU 3), the next menu set is displayed.
•
If you select the EXIT icon, the system returns to the main screen.
Description
30 Zone80 DG Menu
