GeoMax Zone80 DG User Manual

Self-levelling accuracy is defined at 25 °C (77 °F).
Type Value
Self-levelling range ±6°
Type Value
Head speed 5, 10, 20 rps
18474_001
218 mm (8.6")
241 mm (9.5 ") 202 mm (8.0")
± 10% in both axes simultaneously, 15% in one axis with up to 3% in the cross axis
Zone80 DG weight with battery: 3.4 kg/7.4 lbs.
Type Operating times* at 20 °C
Lithium-Ion (Li-Ion pack) 40 h
*Operating times are dependent upon environmental conditions.
☞
Charging the Li-Ion battery pack takes a maximum of five hours.
Temperature
Operating temperature Storage temperature
-20 °C to +50 °C (-4 °F to +122 °F) -40 °C to +70 °C (-40 °F to +158 °F)
Protection against water, dust and sand
Protection
IP67
Dust tight
Waterproof to 1 m temporary immersion.
Self-levelling range
Head speed
Laser dimensions
Grade Capability
Weight
Internal battery
Environmental specifica-
tions
60 Technical Data
