ZTS600 | 144Data Management
.
10.3 Working with GeoMax Office Software
Description The program package is used for the data exchange between the instrument
and a computer. It contains several auxiliary programs in order to support the
instrument.
Installation on a
computer
The installation program can be found on the CD-ROM supplied. Insert the CD
and follow the on-screen instructions. Please note that the software can only
be installed on computers with MS Windows 2000, XP and Vista operating
systems.
For more information refer to the comprehensive online help.
GSI-IDs GSI-IDs continued
11 PtID 41-49 Codes and attributes
21 Horizontal direction 51 ppm [mm]
22 Vertical angle 58 Prism constants
25 Orientation 81-83 (E, N, Z) Target point
31 Slope distance 84-86 (E, N, Z) Station point
32 Horizontal distance 87 Reflector height
33 Height difference 88 Instrument height
