Gerber Technology AccuPlot AP-100 User Manual

Plotter Hardware Components
Hardware Summary 3-3
Note:Note: All locations assume that you are standing at and facing the control panel.
Figure 3-2 Top view of the AccuJet 520
Drive Roller with
independent Grippers
Carriage Assembly
contains the Long-Life Pen
and the Inkjet Assemblies
Control Panel with
Emergency Stop Switch
Power on/off switch
located just above
paper supply roll.
Data connector is
located left of the
power switch.
Paper supply roll
Dancer bar is
located under the
paper supply roll.
Beam
table with
sliding covers
Right Side
Linear Bearing
