Gerber Technology AccuPlot AP-100 User Manual

Offline Operation
Raising and Lowering the Pen 4-7
Raising and Lowering the PenRaising and Lowering the Pen
Tool Up/Tool Down is a toggle function that raises and lowers the pen.
The menu displays the action to be performed, not the current position of the
pen. For example, if the pen is raised, the menu displays Tool Down. If the
pen is lowered, the menu displays Tool Up.
TO LOWER OR RAISE THE PEN
1. From page one of the Offline menu, press the Menu key one time to
display page two.
2. From page two, press F1-TOOL UP/DOWN.
If the pen was up, it lowers to the paper and the Offline menu display
changes as shown below.
If the pen was down, it lifts off the paper and the Offline menu display
changes as shown below.
OFFLINE . . .
TOOL UP SERVO DISABLE
PARAM ENTRY TOOL TMR
OFFLINE . . .
TOOL DOWN SERVO DISABLE
PARAM ENTRY TOOL TMR
