Gerber Technology AccuPlot AP-100 User Manual

Plotter Hardware Components
3-8 Table Orientation
Table OrientationTable Orientation
Some procedures in this guide refer to the X-axis, the Y-axis, or the origin
point. Figure 3-7 shows each axis direction and the GGT default origin.
Figure 3-7 X–axis, Y–axis, and GGT default origin
Y–axis
X–axis
0,0
GGT default origin
