Gerber Technology AccuPlot AP-100 User Manual

Offline Operation
4-28 Diagnostic Tests
TO ACCESS THE DIAGNOSTIC MENUS
1. From page three of the Offline menu, press F2-Diagnostics to display page
one of the Diagnostics menu.
2. From page one of the Diagnostics menu, do one of the following:
• Press F1-Diag Plots to run diagnostic plot tests (page 4-29).
• Press F2-Display Diag to test the control panel display screen (page
4-32).
• Press F3-Key Diag to test control panel keys (page 4-33).
• Press the Menu key to display page two (below). This menu allows
you to check control panel keys.
• Press the Menu key twice to display page three of the Diagnostics
MENU. Page three provides access to Inkjet tests.
• Press F4-Exit to return to the Offline MENU.
DIAGNOSTICS. . .
DIAG PLOTS SERVICE
DISPLAY DIAG EXIT
DIAGNOSTICS. . .
IO DIAGS KEY DIAGS
SERVO DIAGS EXIT
DIAGNOSTICS. . .
INKJET DIAGS
EXIT
